Geolocation from IP

Description

Objective

The Geolocation from IP module accepts an IP address and responds with the geolocation details.

Input	Output
User's IP address	The geolocation and network details, such as: IP Address & Hostname Autonomous System Number(ASN) and Name Location Details The Internet Service Provider(ISP) The Location Coordinates Timezone

Input

The following table provides the complete information on all the input parameters for the module.

Parameter	Description	Mandatory or Optional	Allowed Values	Default Value
ip	The IP address for verification	Optional	Not Applicable	The public IP* address of the end user's system

note

*A Public IP is assigned by your Internet Service Provider (ISP) and is visible on the internet, allowing the module to fetch location data.

In contrast, Private IPs are used within local networks, for example, at home or in an office and cannot be used to retrieve such details, as they are not visible on the public internet.

Success Response

{
  "status": "success",
  "statusCode": "200",
  "metadata": {
    "requestId": "<Unique_Request_ID>",
    "transactionId": "<Transaction_ID>"
  },
  "result": {
    "workflowDetails": {
      "workflowId": "<Workflow_ID>",
      "version": 1
    },
    "applicationStatus": "auto_approved",
    "results": [
      {
        "module": "Geolocation From IP",
        "moduleId": "module_kzPEG0_ip_geolocation_api",
        "apiResponse": {
          "status": "success",
          "statusCode": "200",
          "metadata": {
            "requestId": "<Unique_Request_ID_For_IP>",
            "transactionId": "<Transaction_ID_For_IP>"
          },
          "result": {
            "ipAddress": "<IP_Address>",
            "geoDetails": {
              "as": "<Autonomous_System>",
              "city": "<City>",
              "country": "<Country>",
              "countryCode": "<Country_Code>",
              "isp": "<Internet_Service_Provider>",
              "lat": "<Latitude>",
              "lon": "<Longitude>",
              "org": "<Organization>",
              "query": "<Query_IP_Address>",
              "region": "<Region_Code>",
              "regionName": "<Region_Name>",
              "status": "success",
              "timezone": "<Timezone>",
              "zip": "<Zip_Code>"
            },
            "summary": {
              "action": "pass",
              "details": []
            }
          }
        },
        "attempts": "<Number_of_Attempts>",
        "previousAttempts": []
      }
    ]
  }
}

Success Response Details

Parameter	Type	Description
workflowId	string	The unique ID of the workflow
version	integer	The version number of the workflow
applicationStatus	string	The status of the application
results	array	An array of results for the request
module	string	The name of the module being executed
moduleId	string	The ID of the module
apiResponse	object	Contains the API response details
status	string	The status of the API response
statusCode	string	The status code of the API response
metadata	object	Contains metadata information for the API response
requestId	string	A unique identifier for the API request
transactionId	string	A unique identifier for the API transaction
result	object	Contains the result of the API response
ipAddress	string	The IP address being queried
geoDetails	object	Geolocation details based on the IP address
as	string	The autonomous system's name and number associated with the IP
city	string	The city associated with the IP
country	string	The country associated with the IP
countryCode	string	The country code associated with the IP
isp	string	The internet service provider for the IP address
lat	float	The latitude of the location for the IP
lon	float	The longitude of the location for the IP
org	string	The organization associated with the IP
query	string	The queried IP address
region	string	The region code for the location
regionName	string	The name of the region
status	string	The status of the geolocation query
timezone	string	The timezone of the location for the IP
zip	string	The zip code of the location for the IP
summary	object	A summary of the geolocation result
action	string	The action taken based on the geolocation query result
details	array	An array of detailed actions and codes related to the query result
attempts	string	The number of attempts made to retrieve the geolocation details
previousAttempts	array	An array containing information on previous attempts

Failure Response

{
  "module": "Geolocation From IP",
  "moduleId": "module_kzPEG0_ip_geolocation_api",
  "apiResponse": {
    "status": "failure",
    "statusCode": "400",
    "metadata": {
      "requestId": "<Request_ID>",
      "transactionId": "<Transaction_ID>"
    },
    "result": {
      "error": "Unable to locate geoIp",
      "summary": {
        "action": "fail",
        "details": [
          {
            "code": "136",
            "message": "Unable to locate geoIp"
          }
        ]
      }
    }
  }
}

Error Response

The following is a sample response for a server error.

Internal Server Error

{
  "status": "failure",
  "statusCode": "500",
  "error": {
      "message": "Internal Server Error"
  }
}

Failure and Error Response Details

A failure or error response from the module contains a failure status with a relavant status code and error message. The following table lists all error responses.

Status Code	Error Message	Error Description
400	Unable to locate geoIp	Geolocation details could not be fetched due to invalid or unresolvable IP
500	Internal Server Error	There is an error with HyperVerge's server. Kindly contact the HyperVerge team for resolution.
503	Server Busy	Please contact the HyperVerge team for resolution

Application View

The following image shows the information about the Video OTP module for a sample application available under the Applications tab of the HyperVerge dashboard.

Application Details

The application view presents the geolocation data, based on the queried IP address and displays the results. The set of information displayed in the application view is configurable.

The following table describes the fields available in an application view.

Field Name	Description
Attempted At	The timestamp of the verification process
Summary	If the field value is "pass," it indicates that the application has passed all the configured checks in the module. Otherwise, it reflects a "fail" value.
Results	This field represents the geolocation data returned from the IP address. It can include data points such as City, Country,Region Name, ZIP Code, or any set of information, from the results that the module returns. The data seen in an application view can be configured as per the requirements.
